Temperature Controller

AQ-2011

Application Introduction

3-in-1 air conditioning and underfloor heating thermostat, fan coil thermostat is applied to control the room temperature of the central fresh air system, central air conditioning fan coil system and underfloor water heating system. It can control the room temperature and make it comfortable and energy-saving by turning on and off the fan coil and electric valve at the end of air conditioning system with the comparison of room temperature and setting temperature. (wifi model is optional)

Technical Data

VOLTAGE:AC110-230V, 50/60HZ
TEMPERATURE CONTROL PRECISION:±0.5℃
TEMPERATURE CONTROL RANGE:05℃-45℃
DIMENSION:86MMX86MMX9MM
SELF-CONSUMPTION POWER:<1W
LOAD:3A
SHELL MATERIAL:PC + ABS FLAME RETARDANT
AMBIENT TEMPERATURE:-5℃-50℃
PROTECTION GRADE:IP20

Parameter Details
